T6045
The T6045 Dual‑Spindle is a dual‑spindle model designed for shops that need higher throughput in batch production. Its two independently controlled spindles can machine two different parts at the same time, or run different operations on the same part – all in a single clamping. With an output approaching that of two single‑spindle machines and a machine cost far below a multi‑spindle system, it is an ideal choice for high‑volume production of standard parts, 3C structural components, and automotive parts.
- Product ID
- #2557
- Category
- Drilling and Tapping Center
Description
One Machine. Double the Output.
Independent dual spindles. Complete milling, drilling, and tapping in a single setup.
Double throughput at a controlled cost – built for 3C, automotive, hardware, and mold industries.
• Flexible Machining
Two independent spindles. Milling, drilling, and tapping can be freely combined in one clamping – eliminating repositioning errors.
• Parallel Processing
Process two operations on the same part simultaneously, or machine two different parts at the same time. One operator can run multiple machines.
• Balanced Cost
Significantly lower cost than multi‑spindle systems, with output approaching that of two single‑spindle machines. A practical choice for growing shops on a budget.
• Reliable Operation
Simplified design, fewer failure points, easier maintenance. Built for continuous, long‑run production.
Key Specs: 20,000 rpm Spindle | 1.8 sec Tool Change | 5μm Accuracy | Dual‑Station Parallel Machining
Parameters & Technical Features
| Item | Parameter | Unit |
|---|---|---|
| Table | ||
| Table Size | 1000 × 420 | mm |
| Max. Table Load | 300 | kg |
| T‑Slot Size | 3 × 14 × 125 | mm |
| Travel Range | ||
| X‑Axis Travel | 600 | mm |
| Y‑Axis Travel | 450 | mm |
| Z‑Axis Travel | 350 | mm |
| Spindle Nose to Table Surface | 145 - 495 | mm |
| Spindle Center to Column | 450 | mm |
| Spindle | ||
| Spindle Type | Direct‑Drive | -- |
| Spindle Taper | BT30 | -- |
| Spindle Speed | 20000 | rpm |
| Feed | ||
| Cutting Feed Rate | 0 - 10000 | mm/min |
| X‑Axis Rapid Traverse | 48 | m/min |
| Y‑Axis Rapid Traverse | 48 | m/min |
| Z‑Axis Rapid Traverse | 48 | m/min |
| Tool Magazine (Optional) | ||
| Tool Magazine Capacity | 21 | pcs |
| Max. Tool Diameter(Adjacent Empty) | 60 (80) | mm |
| Max. Tool Length | 200 | mm |
| Max. Tool Weight | 3 | kg |
| Tool Change Time | 2 | sec |
| Accuracy | ||
| Positioning Accuracy (X/Y/Z) | 0.01 | mm |
| Repeatability (X/Y/Z) | 0.005 | mm |
| Air Supply Requirement | ||
| Required Air Pressure | 6 | kgf/cm² |
| Required Air Flow | 0.15 | m³/min |
| Weight | ||
| Machine Weight (Excluding Sheet Metal) | 3100 | kg |
